20w Toolless LED street Light With class II driver
  • 20w Toolless LED street Light With class II driver
  • 20w Toolless LED street Light With class II driver
  • 20w Toolless LED street Light With class II driver
  • 20w Toolless LED street Light With class II driver
  • 20w Toolless LED street Light With class II driver

20w Toolless LED street Light With class II driver

Series Rifle LED Street Light

Model：

ZGSM-ST17-20S / ZGSM-ST17-20S+

Application：

Street | Road | Highway | Parking lot | Bridge | Path


Inquire Now None
20w Toolless LED street Light With class II driver

INQUIRY NOW

PRODUCT DESCRIPTION

Key Features

1.70% energy saving, short ROI period

2. Up to 100, 000hrs @ L70, low maintenance cost

3.World class, approbated quality components (LEDs /Driver /etc.)

4. Support horizontal and vertical mounted, suitable for different light poles

5. Tool-less opening of driver box, ease of maintenance

6. 5 years warranty


Specifications

ModelZGSM-ST17-20S /   ZGSM-ST17-20S+
LED BrandLUMILEDS   3030 OR 5050
Driver BrandInventronics   /Other brands on request
Norminal Wattage20W
Input Voltage100-240/277VAC
Power Efficiency>90%
Power Factor>0.95
Lamp Rated Luminous Efficiency155-170lm/w
Lamp Rated Lumen output3100-3400   lm (Lumen tolerance +/- 5%)
Color Rendering Index70   (80 is optional)
Color Temperature3000K,   4000K, 5000K, 5700K
Photometric TypeType   II, Type III
Optimal Operating Temperature25℃
Storage Temperatures-40°C~50°C
Working EnvironmentBetween-40°C~+50°C,   10%~90%RH
Total Harmonic Distortion<   10%
Lumen Maintenance>   100,000 hours -L70, @25 ºC (77 ºF)
BodyHigh   pressure die-cast aluminum
CoverTempered   glass
RatingIP66   IK10
Protection Class   I (Default) /Class II
CertificationCE, RoHS, ENEC, CB, LM79, LM80, TM-21
Dimming Options1-10V Dimming   (Default) /Timer Dimming
Available on request

NEMA   socket (3/5/7pins), ZHAGA socket, Short cap,

Photocell, Motion sensor, Knife   switch, NTC, OLC,

Solar Compatible, DALI Dimming

Color OptionsGray   (Default) /Black (available on request)
Warranty5   years



FAQ

Fixture   Dimension610 x190 x143mm
Fixture Weight4.7kg
Packing Type1unit   /ctn
Packing Dimension545   x240 x175mm
Packing Weight5.2kg
