38w Highway Light

Series Kmini LED Street Light

Model:

ZGSM-LD38Kmini

Application:

Street | Road | Highway | Parking lot | Bridge | Path


PRODUCT DESCRIPTION

Key Features

1. Wide power range: 28W~57W

2. Special circuit design, single LED’s damage won't affect others' normal work

3. Smart design, low transportation costs

4. Smooth body would greatly diminish dust accumulation and bird droppings heap up.

5. High Lumen output up to 142lm/w with high quality LED chips

6. Designed to last at least 100,000 hours at L70

7. ENEC/ CB/ CE/ RoHS/ IK10 /IP66 /LM79

8. Multiple lighting control options are available, e.g. DALI, 1-10V, photocell.

9. 5 years limited warranty available.


Specifications

Specifications
ModelZGSM-LD38Kmini
LED BrandLUMILEDS® LUXEON 3030
Driver BrandInventronics
Norminal Wattage38W
LED Chip Quantity3030: 56pcs
Input Voltage100-240/277VAC
Power Efficiency>90%
Power Factor>0.95
Lamp Rated Luminous Efficiency136 lm /w
Lamp Rated Lumen output5165 lm (Lumen tolerance +/- 5%)
Color Rendering Index70(80 optional)
Color Temperature3000K or 4000K or 5000K or 5700K
Photometric TypeType II Medium
Optimal Operating Temperature25℃
Storage Temperatures-40°C~50°C
Working EnvironmentBetween-40°C~+50°C, 10%~90%RH
Total Harmonic Distortion< 10%
Lumen Maintenance> 100,000 hours -L70, @25 ºC (77 ºF)
Wind IndexForce 12
Body and Shell MaterialsDie-cast aluminum; PC Lens
Pole Fitter Diameter60mm ( 50mm optional)
RatingIP66 IK10
Protection Class I
SPD10KV (20KV optional)
CertificationCE, ENEC,CB ROHS,LM80,LM79,IP66 IK10,ISTMT
Dimming Options1-10V
Control OptionsPhotocell or Smart control
Color OptionsDeep grey
Warranty5 years



Packing Details

Packing Details
Fixture Dimension447X179X77mm
Fixture Weight2.3 kg
Packing Dimension465X200X100mm
Packing Weight2.7 kg
