ENEC 40w Commercial LED Pole Lights

40w Commercial LED Pole Lights provide an effective way to illuminate walking paths and outdoor spaces by easily providing large areas. LED pole luminaires are mounted on top of the poles to illuminate the area around the poles. Multiple lighting control options are available, e.g. 1-5V, 1-10V, DALI,  photocell and Motion Sensor.

PRODUCT VIDEO

PRODUCT DESCRIPTION

Key Features

● Wide power range: 20W~50W.

● Special circuit design, single LED damage won't affect others' normal work.

● Smart design, low transportation costs.

● Smooth body would greatly diminish dust accumulation and bird droppings heap up.

● High Lumen output up to 160lm/ w with high-quality LED chips.

● Multiple lighting control options are available, e.g. 1-5V, 1-10V, DALI, photocell and motion sensor.

● Designed to last at least 100, 000 hours at L70.


Specifications

ModelZGSM-LD40Kmini
LED BrandLUMILEDS® LUXEON 3030/ 5050
Driver BrandInventronics
Normal Wattage40W
LED Chip Quantity

3030: 56pcs  5050: 22pcs

Input Voltage100-240/277VAC
Power Efficiency>90%
Power Factor>0.95
Lamp Rated Luminous Efficiency3030: 140 lm /w  5050: 150 lm /w
Lamp Rated Lumen output3030: 5600 lm  5050: 6000 lm (Lumen tolerance +/- 5%)
Color Rendering Index70(80 optional)
Color Temperature3000K or 4000K or 5000K or 5700K
Photometric Type3030: Type II Medium  5050: Type II Medium BLS
Optimal Operating Temperature25℃
Storage Temperatures-40°C~50°C
Working EnvironmentBetween-40°C~+50°C, 10%~90%RH
Total Harmonic Distortion< 10%
Lumen Maintenance> 100,000 hours -L70, @25 ºC (77 ºF)
Wind IndexForce 12
Body and Shell MaterialsDie-cast aluminum; PC Lens
Pole Fitter Diameter60mm ( 50mm optional)
RatingIP66 IK10
Protection Class I
SPD10KV (20KV optional)
CertificationCE, ENEC,CB ROHS,LM80,LM79,IP66 IK10,ISTMT
Dimming Options1-10V
Control OptionsPhotocell or Smart control
Color OptionsDeep grey
Warranty5 years


FAQ

1. What are LED pole lights?

LED pole luminaires are mounted on top of the poles and have type III, IV, or V distributions to illuminate the area around the poles. Pillar top lights can be used for decorative outdoor applications with different shapes, sizes, and color finishes.


2. What is the difference between commercial lighting and residential lighting?

Commercial-grade lighting products are made of better quality LED drivers, LED modules, radiators, etc., and last longer than residential-grade products. As a result, they are more durable and last longer than residential lighting options.


3. What are the benefits of LED solutions?

· Significant energy savings - more than 60% as compared to typical street lighting

· Good color rendering, which makes colors appear more natural.

· Long service life - up to 100,000 hours, resulting in lower maintenance costs.

· White light that is uniform and of good quality. LED lighting helps to make spaces safer by improving facial recognition for security and CCTV cameras.

· When light is not required, LEDs can be muted, resulting in extra energy savings. LEDs can also be networked and controlled remotely by connecting them to sensors and controls.
