ShoeBox LED Parking Lot Light
Series K LED Parking Lot Light
Model:
ZGSM-LD90KM
Application:
Street | Road | Highway | Parking lot | Bridge | Path
1. Wide power range: 25W~200W.
2. Special circuit design, single LED’s damage won't affect others' normal work.
3. Tool-less open for easy installation, replacement and maintenance.
4. Power-off protection makes the power automatically off when fixture is opened.
5. Smooth body would greatly diminish dust accumulation and bird droppings heap up.
6. Level bubble makes it easy for the installer to adjust the position of the lamp.
7. High Lumen output up to 150lm/ w with high quality LED chips.
8. Pass the 1000 hour salt spray test.
9. Vertical and horizontal installation both available, adjustable by ±15° in both directions.
10.Multiple lighting control options are available, e.g. DALI, 1-10V, photocell, motion sensor.
11.Designed to last at least 100, 000 hours at L70.
12.Multiple lighting distributions are available.
13.ENEC/ CB/ CE/ RoHS/ IK08 /IP66 /LM79
14. 7 years limited warranty available.
Specifications | |
Model | ZGSM-LD90KM |
LED Brand | LUMILEDS® LUXEON 3030 or 5050 |
Driver Brand | Meanwell HLG series/ Inventronics |
Norminal Wattage | 90W |
LED Chip Quantity | 3030: 144pcs 5050: 72pcs |
Input Voltage | 100-240/277VAC |
Power Efficiency | >90% |
Power Factor | >0.95 |
Lamp Rated Luminous Efficiency | 130-150 lm /w |
Lamp Rated Lumen output | 11700-13500 lm (Lumen tolerance +/- 5%) |
Color Rendering Index | 70(80 optional) |
Color Temperature | 3000K or 4000K or 5000K or 5700K |
Photometric Type | Type I Medium;Type II Medium;Type III Medium |
Optimal Operating Temperature | 25℃ |
Storage Temperatures | -40°C~50°C |
Working Environment | Between-40°C~+50°C, 10%~90%RH |
Total Harmonic Distortion | < 10% |
Lumen Maintenance | > 100,000 hours -L70, @25 ºC (77 ºF) |
Wind Index | Force 12 |
Body and Shell Materials | Die-cast aluminum;Tempered Glass |
Pole Fitter Diameter | 60mm ( 50mm optional) |
Rating | IP66 IK08 |
Protection | Class I ( Class II optional) |
SPD | 10KV (20KV optional) |
Certification | CE, ENEC,CB ROHS,LM80,LM79,IP66 IK08,ISTMT |
Dimming Options | 1-10V or DALI or PWM or Timer |
Control Options | Photocell or Motion sensor or Smart control |
Color Options | Deep grey or Light grey |
Warranty | 7 years |
Packing Details | |
Fixture Dimension | 726 x357 x127 mm |
Fixture Weight | 8.1 kg /17.6 lbs |
Packing Dimension | 785 x415 x205 mm |
Packing Weight | 10.1 kg /22.3 lbs |
