190LM/W High Bay Light

Home  /  Products / LED High Bay Light / 190LM/W High Bay Light
  • 100w led ufo industrial high bay light
  • 100w led ufo industrial high bay light
  • 100w led ufo industrial high bay light
  • 100w led ufo industrial high bay light
  • 100w led ufo industrial high bay light

100w led ufo industrial high bay light

100w led ufo industrial high bay light, Our Helios of high bays was designed to cover a variety of applications, from mines and factories to warehouses, retail stores, and public spaces. Can be equipped with Zigbee wireless dimming and a PIR /MOTION sensor.

PRODUCT DESCRIPTION

Key Features

1. Wide power range: 100W~200W

2. Luminaire efficacy: Up to 190 lm /w

3. 70% energy saving, short ROI period

4. Up to 50, 000hrs @ L70, low maintenance cost

5. Durability, suitable for dry and wet applications

6. Versatile in mounting with wall-mounted, loop hanging, steel chain hanging

7. RoHS compliant, environmentally friendly, no mercury or lead, 100% recyclable

8. 5 years warranty

9. Multiple lighting distributions available

10. CE/ RoHS/ IK08/IP66

Specifications

ModelZGSM-HB09-100S
LED BrandLUMILEDS 3030 or 2835
Driver BrandMOSO Driver
Normal Wattage100W
Input Voltage100-240/277VAC
Power Efficiency>90%
Power Factor>0.95
Lamp Rated Luminous Efficiency145-190lm/w
Lamp Rated Lumen output14500-19000 lm (Lumen tolerance +/- 5%)
Color Rendering Index70 (80 is optional)
Color Temperature4000K, or 5000K
Photometric Type60, 90, OR 110 degrees
Optimal Operating Temperature25℃
Storage Temperatures-40°C~50°C
Working EnvironmentBetween-40°C~+50°C,   10%~90%RH
Total Harmonic Distortion< 10%
Lumen Maintenance> 100, 000 hours -L70, @25 ºC (77 ºF)
BodyDie casting aluminum
CoverPC LENS
RatingIP65 IK10
Protection Class I
CertificationCE, ROHS, LM80
Dimming OptionsNon-Dimming (Default) /0-10V /Zigbee Wireless Dimming
Control OptionsPIR/MOTION sensor
Color OptionsBlack
Warranty5 years

FAQ

What are UFO high bay lights?

UFO LED industrial and miner's lamps are LED lights shaped like UFOs, mainly used for commercial or industrial lighting, such as warehouses, factories, garages, shopping malls, etc., which can illuminate large areas.


What is the best lighting for a warehouse?

The most versatile and energy-efficient option for lighting your warehouse is led luminaires. They use less energy than any other light source and emit comparable or even better lumen outputs. LEDs can be purchased either as complete luminaires for new buildings or as retrofits of existing luminaires.
