Kmini Series Split LED Solar Street light

The Kmini series split led solar street light are truly impressive. It uses high-efficiency solar panels with an efficiency of over 23%, ensuring efficient energy conversion. At the same time, with long-life lithium batteries and efficient MPPT solar charge and discharge controllers, even in continuous rainy days, the street lights can be guaranteed to operate stably for 3 to 5 days, with continuous lighting for 12 hours a day.

In addition, the street light uses high-quality Lumileds chips with a luminous efficiency of up to 156lm/w, ensuring excellent lighting effects. What’s more worth mentioning is that its intelligent controller has functions such as customized dimming curves and microwave sensing.

Inquire Now Produit suivant

PRODUCT VIDEO

PRODUCT DESCRIPTION

Key Features

It can not only adjust the brightness according to actual needs, but also automatically trigger lighting when pedestrians or vehicles approach, thereby maximizing energy saving effects.

Kmini solar street lights are quite suitable for applications in cities and suburbs, especially in areas where the main grid coverage is incomplete or the power supply is unstable. It is undoubtedly an ideal lighting solution. Its high efficiency, stability and environmental protection make it an indispensable part of modern urban construction.

Specifications

Series No	Kmini/Kmini2 Series
Power	20W, 30W, 40W, 50W, 60W, 70W, 80W, 90W, 100W, 110W, 120W, 130W, 140W, 150W
Efficacy	130-156lm/W
Input Voltage	DC 12/24V
Battery Spec	230WH-1843WH or customized
Solar Panel Spec	Monocrystalline silicon 50-400W or customized
IP Rating	IP66
IK Rating	IK10
Beam Angle	Type II
Mounting Option	Side Entry

FAQ

What is Split Solar Street Light？

Split solar street lights mean that solar panels, batteries, and LED lights are designed separately. Unlike integrated street lights and all-in-two solar street lights, split solar street lights are a flexible combination with different capacities for each component.

What is an integrated solar street light?

Integrated solar street lights with built-in lithium iron phosphate batteries, solar panels, and chargers. Independently tiltable LED light sources and pole mounting brackets allow the beam to be focused on roads and solar panels facing the sun. Microwave-based motion sensors for optimizing battery life.

What does MPPT do?

MPPT stands for Maximum Power Point Tracking, a technique that regulates battery pack charging. MPPT charge controllers function similarly to transmissions in cars. When the transmission is in the wrong gear, the wheels do not get maximum power.
