Lithium battery 20w All in One Solar Street Light

Lithium battery 20w all in one solar street light adopts an integrated design, solar panels, lithium batteries, controllers, and LED lights as a whole, which is greatly convenient for customers to install. The high luminous efficiency can ensure the same luminous efficiency under the premise of greatly reducing the system configuration, thereby reducing costs.

PRODUCT VIDEO

PRODUCT DESCRIPTION

Key Features

1. Wide power range: 10W~60W.

2. Special circuit design, single LED damage won't affect others' normal work.

3. High Lumen output up to 145lm/ w with high-quality LED chips.

4. Lithium battery improves the reliability of the luminaire.

5. Monocrystalline silicon solar panels, greatly improving solar energy conversion efficiency.

6. Smart MPPT controller realizes intelligent control of lamps.

7. Multiple lighting control options are available, e.g. motion sensor, and PIR sensor.


Specifications

ModelZGSM-PV502010
LED Number30units
Nominal Power20W
Battery Spec.10AH/11.1V
Solar Panel Spec.Monocrystal 50W /18V
LED BrandPhilips Lumileds 3030 2D
Luminous Flux2600lm
Light type1S
CCT3000K.4000K.5000K.5700K
Charge time<2.5 Hours (Low battery voltage)
Worktime at Energy
-saving Model(30%)
more than 14.5 hours
Discharge Temperature-20℃~+60℃
Charge temperature<60℃
Light control voltage5-11V
mounting height4-5m
space between light12~17m
Pole Diameter FixtureRound pole: Φ60~85mm; Square pole : 60 x60 ~77 x77mm
RatingIP65 IK10
Induction TypeHuman infrared induction or microwave induction function
CertificationCE, ROHS, LM80
warranty period3 years



FAQ

How does the all-in-one solar street light work?

Solar street lights absorb solar energy during the day, and photovoltaic cells convert solar energy into electrical energy, which is stored in batteries. At night, the lights automatically turn on and drain the power that has been stored in the battery.


How to charge a solar lamp without sunlight?

· Use small lights in winter /cloudy weather.

· Use incandescent lamps.

· Use an LED light source.

· Use another charging method.

· Reposition the angle of sunlight to receive more light.

· Use a mirror to redirect light to your solar lamp.


How to choose solar street lights?

Here are three key factors for a properly sized, reliable solar street light that depends on a healthy array-to-load ratio, adequate battery capacity and backup power, and efficient LED luminaires and operating profiles.
